Blackmagic Design Mini Converter Sync Generator for Precise Video Synchronization
The Blackmagic Design Mini Converter Sync Generator is a professional-grade device designed to generate high-quality video sync signals for broadcast and production environments. Featuring multiple output formats and advanced clocking capabilities, this sync generator ensures precise synchronization for all your video equipment.
BLACKMAGIC DESIGN's Mini Converter Sync Generator is a visual accessories with the following characteristics:
Connections
- Analog Video Outputs: 6 x common Blackburst or Tri Level reference outputs
- SDI Rates: 270Mb, 1.5G
- Multi Rate Support: Via mini switches
- Updates and Configuration USB
Standards
Analog Format Support: 525i29.97 NTSC, 625i25 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080PsF23.98, 1080PsF24, 1080i50, 1080i59.94, 1080i60
Software
- Software Control: Mac™ and Windows™ software upgrade via USB
- Internal Software Upgrade: Via included updater application
Operating Systems
- Mac icon Mac 10.12 Sierra, Mac 10.13 High Sierra or later
- Windows Icon Windows 8.1 or Windows 10
Settings Control
Mini Switches or USB software
Power Requirements
- Power Supply: +12V universal power supply included with international socket adapters for all countries. Cable tie point
- Power Consumption: 3.00 Watts
- Operational Voltage Range: 12V DC
Manufacturer :
Blackmagicdesign
Model :
MINI-CONVERTER-SYNC-GENERATOR
Height (cm) :
2.3000
Length (cm) :
9
Width (cm) :
12.3000
